Specificaties
| Uitgangsspanning |
| Laadstroom (maximum) |
20 A |
| Laadspanning - Bulk |
28.4 - 31 V |
| Laadspanning - Float |
26.8 - 27.6 V |
| Laadspanning - Equalize |
32.0 V |
| Laadkarakteristiek |
3-step (Bulk/Absorption/Float) |
| Aantal laaduitgangen |
3 |
| Accu type's |
GEL, AGM, WET, Lithium |
| Terugloopstroom |
< 2 mA |
| LADER INPUT |
| AC Ingangsspanning (nominaal) |
100, 120, 220, 230, 240 VAC |
| AC Ingangsspanning bereik |
90 - 265 VAC |
| AC Ingangsfrequentie bereik |
47 - 63 Hz |
| Max. verbruik |
700 W |
| Power factor correctie |
Yes |
| Rendement |
> 82% |
| Beveiligingen en technische specificaties |
| Accu verkeerd aangesloten |
Yes, unit shutdown |
| Overladen |
Yes, unit shutdown |
| Overtemperatuur |
Yes, unit de-rated and shutdown |
| Kortsluiting |
Yes, unit shutdown |
| DC zekering |
2*20A, 32V |
| Koeling |
Force air ventilation |
| Temperatuurinstelling |
Hot, Normal, Cold (no sensor connected) |
| Battery Temperature Sensor |
Yes included with 1.5mtr cable |
| Accu temperatuursensor poort |
RJ12 (battery temp. sensor use) |
| Digital Display Port |
RJ12 (optional display panel use) |
| Display |
| LCD Display |
Charging status, Battery Voltage |
| Waarschuwing en foutcode |
A01-02, E01-09 |
|
