| TECHNICAL SPECIFICATIONS |
| Battery NR code |
4IFP227/415/315 |
| Height (mm) |
313.00/314.00 |
| Width (mm) |
413.50 / 414.50 |
| Depth (mm) |
225.00 / 226.00 |
| Weight |
21kg |
| Nominal voltage (V) |
13.2 V |
| Maximum voltage |
15.4 VDC |
| End charge voltage |
14.6 VDC |
| Max charge current 100/c |
100 A |
| Max float charge current |
33 A |
| Minimum battery voltage |
8 VDC |
| Minimum float charge |
10 VDC |
| Max discharge current 3/C |
300 A |
| Prolonged discharge current (max) |
33 A |
| Pulsed discharge current (10 sec) |
800 A |
| Pulsed discharge current (60 sec) |
500 A |
| Usable battery capacity at 20°C |
100 Ah/ 1320 Wh |
| Usable battery capacity at - 20 °C |
65 Ah/ 858 Wh |
| Usable capacity / in comparison to lead acid battery |
200 Ah |
| Charge method |
CCCV (Constant voltage) |
| Temperature range (charging) |
0°C to 45°C |
| Temperature range (discharging) |
-20°C to +60°C |
| Temperature range (storage) |
-20°C to +60°C |
