Art.Nr.:
Victron Argodiode 80 - 2Sc Diode Isolator met compensatie Diode - 2 Batterijen 80A
Victron Argodiode 80 - 2Sc Diode Isolator met compensatie Diode - 2 Batterijen 80A
Inclusief BTW (21%) Verzendinformatie*
| Victron Argodiode 80 - 2Sc Diode Isolator met compensatie Diode - 2 Batterijen 80A |
 |
| In de rubriek Victron vindt u de producten en prijzen van Victron. Een selectie Victron producten die u kunt kopen zoals een omvormer, omvormer lader, acculader, scheidingstransformator, dc-dc converter, transfer switch, lynx en dc distributie, zekeringen, ve net, remote paneel, esp, data kabel, interface, accu monitor, batterij isolator, walstroom kabel, solar laadregelaar, zonnepaneel, accu, agm, gel, grid inverter, lithium accu. Volledige fabrieksgarantie op de Victron producten. Verzenden of afhalen is mogelijk. |
Tips en adviesDe gerelateerde producten in de rubrieken Omvormer Lader en Acculader en Omvormer zijn voor u mogelijk ook interessant. |
ContactHeeft u een vraag. Neem contact met ons op per Email voor tips en advies over de Victron Argodiode 80 - 2Sc Diode Isolator met compensatie Diode - 2 Batterijen 80A. |
Specificaties
Victron Energy Argodiode 80-2SC Diode Isolator with compensation diode - 2 Batteries 80a Diode battery isolators allow simultaneous charging of two or more batteries from one alternator, without connecting the batteries together. Discharging the accessory battery for example will not result in also discharging the starter battery. The Argo battery isolators feature a low voltage drop thanks to the use of Schottky diodes: at low current the voltage drop is approximately 0,3 V and at the rated output approximately 0,45 V. All models are fitted with a compensation diode that can be used to slightly increase the output voltage of the alternator. This compensates for the voltage drop over the diodes in the isolator. Please ask for specialist advice when installing a diode isolator. Simply inserting the isolator in the cabling between the alternator and the batteries will slightly reduce charge voltage. The result can be that batteries are not charged to the full 100% and age prematurely. Alternator energize input Some alternators need DC voltage on the B+ output to start charging. Obviously, DC will be present when the alternator is directly connected to a battery. Inserting a Diode or FET splitter will however prevent any return voltage/current from the batteries to the B+, and the alternator will not start. The new “AC” diode isolators feature a special current limited energize input that will power the B+ when the engine run/stop switch is closed. Features:
|
