Garmin MAP 720S Plotter Plus Sounder

GPS MAP 720 is a stand-alone touchscreen chartplotter that brings a new level of functionality to your vessel. Featuring a brilliant 7-inch display, GPSMAP 720 puts all the information you need right at your fingertips. GPSMAP 720 is preloaded with marine charts for the UK and Ireland. In addition, GPSMAP 720 accepts radar input and offers full NMEA 2000® connectivity for greater convenience when adding extra sensors. Explore the Seas

GPSMAP 750 contains preloaded coastal charts for the UK and Ireland. For all other areas, GPSMAP 720 has a worldwide basemap. GPSMAP 720 also features an internal, high-sensitivity GPS receiver for superior satellite tracking and quicker acquisition times.

Input is easy with GPS MAP 720. Whether you’re changing course or simply reviewing information in front of you, the intuitive touchscreen interface enables simple operation. The unit also offers flexible brightness levels for daytime readability along with low-light dimming during night use. And with a widescreen display that’s rugged and waterproof, it’s made to perform in any situation.

Featuring a built-in radar port, GPS MAP 720 can be interfaced with Garmin’s line of affordable GMR marine radar systems. Whether you’re adding radar now or in the future, you’ll enjoy the convenience of “plug-and-play installation” as well as the power, range and high-definition targeting of our proven radar offerings.

GPSMAP 720s comes standard with a 1kW-capable sonar transceiver. This powerful sonar can help you define fish targets and underwater structures as far down as 610 metres (2000 feet) when used with a 1kW transducer¹.

With the optional BlueChart® g2 Vision SD card, you can add a whole new dimension of exceptional features to your chartplotter.

• MarinerEye view and FishEye view provide you with a 3-dimensional perspective of map information, both above and below the waterline.
• High-resolution satellite images and aerial photographs help you orient yourself in unfamiliar areas.
• Auto Guidance technology searches through all relevant charts to create a route you can actually follow — one that avoids obstacles, shallow water, buoys and other obstructions.

GPSMap 720s Sounder features:

• Power output: 1000 watts (RMS) 8000 watts (peak to peak), opt. 1kW xdcr
• 500 watts (RMS) 4000 watts (peak to peak), opt. dual frequency xdcr
• Depth: 2,000 feet / 600 meters (opt. dual freq., 1kW xdcr), 1,500 ft (opt. dual freq., 500 kW xdcr)
• UltraScroll high rep rate sonar provides lightning-fast screen updates
• AutoGain technology enhances target visibility
• See-Thru technology: shows weak and strong returns simultaneously
• Water temperature log graphically records water temp data
• A-scope
• Whiteline
• Adjustable depth line helps gauge desired fishing levels and bottom clearance
• Split zoom display offers a closer look at fish targets and bottom structure
• 2X, 4X, bottomlock zoom – plus, a new manual zoom control for a continuous sonar image while adjusting the range and magnification
• Adjustable keel offset
• Alarms for fish size, shallow water, deep water and low battery
